inrevium Industrial Grade SOM

  • Part Number: TB-7Z-IAE
  • Device Support:
  • Vendor: Tokyo Electron Device Ltd.
  • Ecosystem Program Tier: Certified

Product Description

inrevium TB-7Z-IAE is an industrial-grade small form-factor System on Module (SOM) integrating the Xilinx Zynq®-7000 SoC, two Gigabit Ethernet, DDR3 (512M Byte), Flash (16M Byte), FRAM(64Kbit) and expansion IO connector. The SOM Development Kit includes a reference carrier board which has CameraLink, USB, CAN and schematics to assist in development. This SOM is designed for low-mid volume industrial OEM applications which requires high-throughput and flexible CPU and FPGA infrastructure for highly-integrated embedded systems.


Key Features and Benefits

  • Device : XC7Z020-CLG400I
  • DDR3 SDRAM 512MByte
  • QSPI Flash 16MByte
  • 64Kbit Non-volatile F-RAM
  • Expansion IO Connector
  • Gigabit Ethernet x 2
  • Socket for microSD card
  • JTAG
  • Power Supply:Single DC5V operation
  • Board size:H60xW85(mm)

What's Included

  • RoHS compliant Zynq-7000 SoC Industrial Grade SOM
