AMD Virtex UltraScale+ FPGA VCU1525 Acceleration Development Kit

by: AMD

The Virtex UltraScale+ FPGA Acceleration Development Kit is an excellent starting point for hyperscale application developers.

Overview

Important Notice:

This development kit has been discontinued per PDN advisory XCN18025 and is no longer offered for sale.  The solutions targeted for this product will not be updated moving forward with limited support available from AMD.

Product Description

Ideal for data center application developers wanting to leverage the advanced capabilities of Virtex™ UltraScale+™ FPGAs. This PCIe® development board is accessible in the cloud and on-premise with the frameworks, libraries, drivers and development tools to support easy application programming with OpenCL™, C, C++ and RTL through the AMD SDAccel™ Development Environment.

Passively Cooled Version


Key Features & Benefits

  • Specialized reprogrammable hardware for computationally intensive applications, specifically targeting the fast-growing markets for live video transcoding, data analytics, genomics, and machine learning
  • Dual slot PCIe full-length, full height form-factor compliant
  • Delivers 10-100x performance acceleration over server CPUs with a board designed to support up to 225W
  • SDAccel platform reference design for custom board support
  • Supported with SDAccel Development Environment for OpenCL, C, C++ and RTL
  • VU9P Virtex UltraScale+ FPGA
  • 21 TOPs (8-bit integer precision)
  • 346Mb on chip memory
  • 64GB on board DDR4 DIMM memory

Featured AMD Devices

Featuring the XCVU9P-L2FSGD2104E FPGA

System Logic Cells (K) 2,586
DSP Slices 6,840
Memory (Mb) 345.9
GTY 32.75Gb/s Transceivers 76
I/O 676
virtex-ultrascale-plus-bk-chip

Product Information

Specifications

Board Features

Featuring the VCU1525 Board

VCU1525 Board

Memory

  • 4 - 16GB DDR4 DIMMs

Power & Thermal

  • Active Cooling
  • 225W Max Dynamic Power Sourcing
  • Up to 75W max from PCIe Edge Connector
  • Additional 150 W max supplied from PCIe Aux Power Connector

Configuration

  • FPGA Configuration via JTAG thru Micro USB Port
  • QSPI Configuration flash memory

Communication & Networking

  • Two QSFP28 100G Interfaces
  • PCIe Gen3 x 16 or Gen4 x8 via Edge Connector

Featured AMD Devices

Featuring the XCVU9P-L2FSGD2104E FPGA

System Logic Cells (K) 2,586
DSP Slices 6,840
Memory (Mb) 345.9
GTY 32.75Gb/s Transceivers 76
I/O 676
virtex-ultrascale-plus-bk-chip

What's Inside

What's Inside

VCU1525 board featuring the XCVU9P-L2FSGD2104E

Vivado™ Design Suite: Design Edition Voucher Code

Node locked & Device-locked to the XCVU9P FPGA, with 1 year of updates

USB Micro Cable

Resources

Documentation

Filter Documentation

Step 1: Board Revision

Step 2: Tools Version

Step 3: Show Documentation

Click to update search results table
Tools & IP

Design Tools

Name Description License Type
Vivado Design Suite Design Edition The AMD Vivado™ Design Suite is a revolutionary IP and System Centric design environment built from the ground up to accelerate the design for FPGAs and SoCs. Node locked and device-locked to the XCVU9P FPGA, with one year of updates.

Supports Dynamic Function eXchange
SDAccel Development Environment SDAccel is a development environment for OpenCL applications targeting PCIe®-based AMD FPGA accelerator cards. This environment enables concurrent programming of the system processor and the FPGA logic without the need for RTL design experience. Node locked and device-locked to the XCVU9P FPGA, with one year of updates.
Dynamic Function eXchange Dynamic Function eXchange is the ability to dynamically modify blocks of logic by downloading partial bit files while the remaining logic continues to operate without interruption. AMD Dynamic Function eXchange technology allows designers to change functionality of the accelerator board on the fly, eliminating the need to fully reconfigure and re-establish PCIe links while reloading. Node locked and device-locked to the XCVU9P FPGA, with one year of updates.

Intellectual Property

Name Description License Type
DDR4 SDRAM Controller DDR4 SDRAM controller is a free IP core in the Vivado IP Catalog. No-Charge IP
DMA for PCI Express (PCIe) Subsystem The AMD LogiCORE™ DMA for PCI Express (PCIe) implements a high performance, configurable Scatter Gather DMA for use with the PCI Express 3.x integrated block.  The IP provides an optional AXI4 or AXI4-Stream user interface. No-charge IP
AMD SmartConnect Technology The AMD SmartConnect Technology enables unprecedented levels of performance for the UltraScale+™ device portfolio, by solving the system interconnect bottlenecks on high density, multi-million system logic cell designs. No-charge IP
SDAccel Platform Reference Design for Custom Board Support SDAccel projects are compiled against a target platform. The SDAccel Platform Reference Design is the combination of board and hardware/software infrastructure components on which the kernels of an OpenCL application are executed.  This reference design is intended to be used as a starting point to help platform developers add SDAccel support for their custom PCIe boards. No-charge IP
Training & Support
Default Default Title Date
Getting Started

Set Up the VCU1525 Accelerator Card

2018.3

Download the Xilinx Runtime and Deployment Shell.

1.

Download the Xilinx Runtime

The Xilinx runtime (XRT) is a low level communication layer (APIs and drivers) between the host and the card.

IMPORTANT: Please enter the following command before installing the XRT:

RedHat:

sudo yum-config-manager --enable rhel-7-server-optional-rpms

sudo yum install -y https://dl.fedoraproject.org/pub/epel/epel-release-latest-7.noarch.rpm

CentOS:

sudo yum install epel-release


2.

Download the Deployment Shell

The deployment shell is the communication layer physically implemented and flashed into the card.

Note:

The VCU1525 will leverage this shell for application development, though the card itself is for development only and was not qualified for volume deployment as part of an end system.


Develop Your Own VCU1525 Accelerated Applications

If you are a developer, download these additional files.


4.

Download SDAccel Design Environment

The AMD SDAccel IDE provides a framework for developing accelerated applications.
