Expanding the SoC Portfolio

Xilinx’s SoC portfolio integrates the software programmability of a processor with the hardware programmability of an FPGA, providing you with unrivaled levels of system performance, flexibility, and scalability. The portfolio gives your designs overall system benefits of power reduction and lower cost with fast time to market. Unlike traditional SoC processing solutions, the flexible programmable logic provides you with optimization and differentiation, allowing you to add the peripherals and accelerators you need to adapt to a broad base of applications.

Cost-Optimized

Zynq-7000 SoC
Artix Devices

Dual Arm® Cortex®-A9

Zynq-7000S SoC
Artix Devices

Single Arm Cortex-A9

Mid-Range

Zynq UltraScale+ MPSoC
CG Devices

Dual Arm Cortex-A53
Dual Arm Cortex-R5

Zynq-7000 SoC
Kintex Devices

Dual Arm Cortex-A9

High-End

Zynq UltraScale+ MPSoC
EV Devices

Quad Arm Cortex-A53
Dual Cortex-R5 + GPU + Video Codec

Zynq UltraScale+ MPSoC
EG Devices

Quad Arm Cortex-A53
Dual Cortex-R5 + GPU

High-End

Zynq UltraScale+ RFSoC
with RF Data Converters

Quad Arm Cortex-A53
Dual Cortex-R5

Zynq UltraScale+ RFSoC
with SD-FEC Cores

Quad Arm Cortex-A53
Dual Arm Cortex-R5

Zynq UltraScale+ RFSoC
with RF Data Converters & SD-FEC Cores

Quad Arm Cortex-A53
Dual Arm Cortex-R5

Xilinx SoC, MPSoC and RFSoC Feature Summary

Processing System
 Zynq-7000 SoC Zynq UltraScale+ MPSoC Zynq UltraScale+ RFSoC
Application Processing Unit Single/Dual-core Arm Cortex-A9 MPCore™ up to 1GHz Dual/Quad-core Arm Cortex-A53 MPCore up to 1.5GHz Quad-core Arm Cortex-A53 MPCore up to 1.33GHz
Real-Time Processing Unit - Dual-core Arm Cortex-R5 MPCore up to 600MHz Dual-core Arm Cortex-R5 MPCore up to 533MHz
Multimedia Processing - GPU Arm Mali™-400 MP2 up to 667MHz,
Video Codec supporting H.264-H.265		 -
Dynamic Memory Interface DDR3, DDR3L, DDR2, LPDDR2 DDR4, LPDDR4, DDR3, DDR3L, LPDDR3 DDR4, LPDDR4, DDR3, DDR3L, LPDDR3
High-Speed Peripherals USB 2.0, Gigabit Ethernet, SD/SDIO PCIe® Gen2, USB3.0, SATA 3.1, DisplayPort, Gigabit Ethernet, SD/SDIO PCIe® Gen2, USB3.0, SATA 3.1, DisplayPort, Gigabit Ethernet, SD/SDIO
Security RSA, AES, and SHA, Arm TrustZone® RSA, AES, and SHA, Arm TrustZone RSA, AES, SHA, Arm TrustZone
Max I/O Pins 128 214 214
Programmable Logic
 Zynq-7000 SoC Zynq UltraScale+ MPSoC Zynq UltraScale+ RFSoC
Max Logic Cells /
System Logic Cells (K)		 444 1,143 930
Max Memory (Mb) 26.5 70.6 60.5
Max DSP Slices 2,020 3,528 4,272
33G Transceivers - - 16
Max I/O Pins 250 668 408
RF Signal Chain
 Zynq-7000 SoC Zynq UltraScale+ MPSoC Zynq UltraScale+ RFSoC
Max ADCs - - 16
Max DACs - - 16
Soft-Decision FEC Cores - - 8
