TySOM-2-FMC-INTF

  • Part Number: TySOM-2-FMC-INTF
  • Device Support:
  • Vendor: Aldec, Inc.
  • Program Tier: Member

Product Description

TySOM-2-FMC-INTF daughter board is designed to provide advanced serial data connectivity by having PCIe, Ethernet 10/100/100, QSFP+, USB 2.0, UART and I2C. It also includes NAND, SPI and EEPROM memory as well as micro SD card socket. This daughter board is compatible with the boards that support FMC HPC connector such as TySOM-2-7Z045, TySOM-2-7Z100 and TySOM-2-7Z030.


Key Features and Benefits

  • 40× Gold pin
  • Ethernet 10/100/100
  • FMC HPC standard Connector
  • I2C
  • PCIe
  • QSFP+
  • UART
  • USB 2.0

What's Included

  • 1x Ethernet 10/100/1000
  • 1x UART Connector
  • 1x USB 2.0
  • 2x 32 Mb SPI Flash Memory
  • 3x Oscillator (100MHz, 156.25MHz and 200MHz)
  • 4 Gb NAND flash memory
  • 40× Gold pin
  • 64 kb EEPROM
  • 8× User LED and switches
  • FMC HPC standard connector compliant with VITA 57.1-2010
  • • I2C Connector
  • • Micro SD Card Socket
  • • PCI-Express Connector
  • • QSFP+ Connector
