Functional Safety
Highest Levels of Safety and Reliability
Xilinx provides a comprehensive TUV SUD certified design flow solution for our customers to simplify and accelerate certifications based on functional safety specifications across Aerospace & Defense, Automotive, Medical and Industrial markets where safety and reliability are key.
Functional Safety Standards Supported
| Application | Standard |
|---|---|
| Automotive | ISO 26262 |
| Industrial and Medical | IEC 61508, IEC 62061 and ISO13849 |
| Aerospace & Defense |
DO-254/DO178b |
Xilinx Unique Value Proposition
Xilinx has decades of proven success and experience across a wide variety of mission-critical industries and applications. Our customers choose our portfolio of FPGAs and SoCs for to enable:
- Configurability and increased performance at lower power
- Integration of complex and complete systems into a single device
- Reliability and long product life time
- Faster time to market
Certified Hardware and Software Design Tools
- Design and verification tools certified for use in Functional Safety applications
- Certified Compiler tools
- Functional Safety Certificate and Reports
- Functional Safety Package
Certified Methodologies & IPs
- Certified functional safety design methodologies enable integration of safety and non-safety functions in the same device
- Isolation Design Flow (IDF) and Vivado Isolation Verifier (VIV) / Isolation Verification Tools (IVT) provide a certified methodology to separate areas on a single device. Designs placed into these regions are physically isolated. The areas can be changed at any time without impacting other isolated regions, proven by the VIV/IVT tools (impact analysis)
- Certified Soft Error Mitigation (SEM) IP cores perform Single Event Upset (SEU) detection, correction, and classification for configuration memory. The cores utilize device primitives such as ICAP and FRAME_ECC to clock and observe the Readback CRC feature as part of the SEU detection function. For SEU correction, the IP cores perform the necessary operations to locate and correct errors. For SEU classification, the IP cores use Xilinx Essential Bits technology to further increase system availability.
Assessed Safety Concept Design
The Zynq®-7000 SoC has been reviewed and assessed for on-chip redundancy by TuV Rheinland. This Safety Concept Design study states Xilinx technology can be used to create a single chip solution that will support 2 independent safety channels for SIL3 safety functions referencing IEC61508 Part2 Annex-E.
Functional Safety Lounge
The Functional Safety Lounge provides access to solutions, documentation and additional resources to subscribers.
For paid subscribers only, log in.
Functional Safety Working Group 2022 (a Virtual Event)
For 2022 Xilinx is offering two Virtual Functional Safety Working Group Events. One 3-day event (Event #1 – EMEA Time Zone) and a 2-day Event (Event #2 – NA Time zone). The content will be the same for both events so you can pick the day/times that work for you. Stay home, stay safe but still be able to attend these events for great Xilinx Functional Safety presentations and an opportunity to ask questions.
Event #1 (3 days)
Event #2 (2 days)
*Please download the Agenda for actual times for each day.
The Xilinx Functional Safety Working Groups (FSWG) are an annual FREE event in North America and Europe that brings together Xilinx Industrial, Automotive and Avionics customers, academic representatives, Xilinx Alliance Members and certification authorities to discuss the latest Functional Safety topics.
The Xilinx Functional Safety Working Group provides an excellent forum for participants to learn from Xilinx functional safety leaders and where attendees can connect with their functional safety peers in the industry. Attendees will develop a better understanding of the industry’s safety requirements for today and tomorrow and learn about innovative and unique solutions coming from Xilinx.
Don’t miss this chance to explore the latest technology innovations from Xilinx and solve your design challenges!
ALL PARTICIPANTS WILL REQUIRE CURRENT NDA AGREEMENTS WITH XILINX OR AMD.
If you have any questions about the event please contact, safety_solutions@xilinx.com.
Some Industrial IoT products need all elements of the Xilinx IIoT Solutions Stack, all need some. The Xilinx IIoT Solutions Stack is comprised of optimized Xilinx and Ecosystem building blocks and solutions used across Industrial and Healthcare IoT platforms. Starting from scratch is never something you will have to do with a Xilinx-based Industrial IoT system. Minimize development time and cost and maximize design reuse on your next Industrial IoT platform by exploring the different elements of the Xilinx IIoT Solutions stack.
