The AMD Varium™ C1100 is a blockchain developer card designed to accelerate compute-intensive blockchain applications, including transaction validation and hash calculations used in most Proof of Work (PoW) and Proof of Stake (PoS) algorithms. The large FPGA Fabric on the AMD Varium C1100 card allows users to implement parallel computational pipelines and run multiple hashing algorithms in parallel to deliver the highest performance with the lowest power consumption.
Built on AMD UltraScale+ architecture, the Varium™ C1100 accelerator card provides a compact single slot, full-height, half-length form factor while operating up to 75W maximum power (passively cooled). The card features dual QSFP28 networking I/O capable of supporting 8 x 25 Gb/s, PCI Express® (PCIe®) Gen3x16 or gen4x8, and 8GB of HBM.
A USB interface provides debugging and programming support. It allows users access to the BMC for system monitoring and control, FPGA UART for bitstream connectivity, and FPGA JTAG for Vivado programming and debugging.
The Varium accelerator card can be easily programmed using Vitis™ development environment from AMD, enables crypto miners to develop different mining algorithms in high-level programming languages such as C and C++.
Performance
Power
Adaptable
Networking
Card Specifications | Varium C1100 (V-C1100-P00G-PQ-G-P) |
---|---|
Compute Resources | |
Look-up Tables(LUTs) | 872 |
Registers | 1,743 |
DSP Slices | 5,952 |
Dimensions | |
Height | Full Height |
Length | Half Length |
Width | Single Slot |
Memory | |
HBM Memory Capacity | 8 GB |
HBM Total Bandwidth | 460 GB/s |
Internal SRAM Capacity | 28 MB |
Internal SRAM Total Bandwidth | 24 TB/s |
Physical Interfaces | |
PCI Express® | Gen3x 16, 2 x Gen4x 8 |
Network Interfaces | Dual QSFP28 (2 x 100Gbps) |
Micro-USB Connector | Yes |
Tool Support | |
Vitis Developer Environment | Yes |
Vitis Platform | Gen3x4 XDMA1 |
Vivado Design Suite | Yes |
Power and Thermal | |
Maximum Total Power | 75W |
Thermal Cooling | Passive |
Note: 1 V-C1100-P00G-PQ-G card supports PCIe Gen3x4 deployment platform shells for Blockchain solution
Getting started with the Varium C1100 Blockchain Accelerator Card is quick and easy. View our Quick Start Videos to get started today.
Quick Start Videos | |
---|---|
Installing Varium C1100 Blockchain Accelerator Cards for ETH Mining | https://www.xilinx.com/video/accelerator-card/installing-varium-blockchain-accelerator-cards-for-eth-mining.html |
Installing ETH Mining Software for Varium | https://www.xilinx.com/video/accelerator-card/installing-eth-mining-software-varium-blockchain-accelerator-card.html |
Running EthereumMiner with on Dell Servers with Varium | https://www.xilinx.com/video/accelerator-card/running-ethereumminer-on-dell-servers-varium-blockchain-accelerator.html |
Users who use high level programming languages such as C/C++ can use Vitis™ software platform for targeting the Varium accelerator card. Steps to deploy and develop using Vitis are given below. Long-time FPGA designers might want to use traditional design flows, such as RTL or HLx. This flow does not require installing the Vitis platform.
Supported Operating Systems | |
---|---|
Tested Operating Systems | https://support.xilinx.com/s/article/XRT-Xilinx-Runtime-version-2021-2-2-12-Tested-Operating-Systems?language=en_US |
RedHat/CentOS 7.x, 8x | ||
---|---|---|
Xilinx Run Time(XRT) | 2021.2 | https://www.xilinx.com/bin/public/openDownload?filename=xrt_202120.2.12.427_7.8.2003-x86_64-xrt.rpm https://www.xilinx.com/bin/public/openDownload?filename=xrt_202120.2.12.427_8.1.1911-x86_64-xrt.rpm |
Deployment Target Platform | 2021.2 | https://www.xilinx.com/bin/public/openDownload?filename=xilinx-u55n-gen3x4-xdma-noarch_2-3349913.rpm.tar.gz |
Development Target Platform | 2021.2 | https://www.xilinx.com/member/forms/download/eula-xef.html?filename=xilinx-u55n-gen3x4-xdma-2-202110-1-dev-1-3352284.noarch.rpm |
For development using RTL and HLx, follow these steps:
Explore Vitis Ethereum Mining library on the AMD GitHub mine Ethereum on the Varium accelerator card.
$2371 per board
Lead Time: 4 weeks (max order qty 10)
Part Number: V-C1100-P00G-PQ-G
