The Zynq®-7000 All Programmable SoC (AP SoC) family integrates the software programmability of an ARM®-based processor with the hardware programmability of an FPGA, enabling key analytics and hardware acceleration while integrating CPU, DSP, ASSP, and mixed signal functionality on a single device. Consisting of single-core Zynq-7000S and dual-core Zynq-7000 devices, the Zynq-7000 family is the best price to performance-per-watt, fully scalable SoC platform for your unique application requirements.
Click to enlarge
Zynq-7000S devices feature a single-core ARM Cortex™-A9 processor mated with 28nm Artix®-7 based programmable logic, representing the lowest cost entry point to the scalable Zynq-7000 platform. Available with 6.25Gb/s transceivers and outfitted with commonly used hardened peripherals, the Zynq-7000S delivers cost-optimized system integration ideal for industrial IoT applications such as motor control and embedded vision.
Click to enlarge
Zynq-7000 devices are equipped with dual-core ARM Cortex-A9 processors integrated with 28nm Artix-7 or Kintex®-7 based programmable logic for excellent performance-per-watt and maximum design flexibility. With up to 6.6M logic cells and offered with transceivers ranging from 6.6Gb/s to 12.5Gb/s, Zynq-7000 devices enable highly differentiated designs for a wide range of embedded applications including multi-camera drivers assistance systems and 4K2K Ultra-HDTV.
|Smarter, Optimized, and Most Secure Solution||
|Unmatched Integration, Performance, and Power||
|Devices||Z-7007S, Z-7012S, Z-7014S||Z-7010, Z-7015, Z-7020||Z-7030, Z-7035, Z-7045, Z-7100|
|Processor Core||Single-core ARM® Cortex™-A9 MPCore™||Dual-core ARM Cortex-A9 MPCore|
|Maximum Frequency||Up to 766MHz||Up to 866 MHz||Up to 1GHz|
|External Memory Support||DDR3, DDR3L, DDR2, LPDDR2|
|Key Peripherals||USB 2.0, Gigabit Ethernet, SD/SDIO|
|Dedicated Peripheral Pins||Up to 128||Up to 128||128|
|Logic Cells (K)||23||55||65|
|Block RAM (Mb)||1.8||2.5||3.8|
|Maximum I/O Pins||100||150||200|
|Maximum Transceiver Count||-||4||-|
|Logic Cells (K)||28||74||85||125||275||350||444|
|Block RAM (Mb)||2.1||3.3||4.9||9.3||17.6||19.1||26.5|
|Maximum I/O Pins||100||150||200||250||362||362||400|
|Maximum Transceiver Count||-||4||-||4||16
For SoC designers looking for a familiar, yet powerful development environment to shorten design time, and ensure scalability and re-use, Xilinx and its third party ecosystem provide a comprehensive suite of tools and methodologies to address bottlenecks in hardware and embedded development, system-level integration, and implementation.
