Spartan 6 FPGA SP605 Evaluation Kit

by: AMD

The Spartan™ 6 FPGA SP605 Evaluation Kit delivers all the basic components of hardware, design tools, IP, and reference designs enabling development right out of the box.

Overview

Important Notice

This evaluation kit has been discontinued and is no longer offered for sale.  The solutions targeted for this product will not be updated moving forward with limited support available from AMD.

Product Description

Accelerate Your Designs – Right Out of the Box

The Spartan™ 6 FPGA SP605 Evaluation Kit delivers all the basic components of hardware, design tools, IP, and reference designs enabling development right out of the box. This kit provides a flexible environment for system design and provides pre-verified reference design and examples on how to leverage features such as high-speed serial transceivers, PCI Express®, DVI, and/or DDR3. This kit includes an industry-standard FMC (FPGA Mezzanine Card) connector for future scaling and customization to specific applications and markets.


Key Features & Benefits

  • Develop networking applications with 10-100-1000 Mbps Ethernet
  • Hardware, design tools, IP, and pre-verified reference designs
  • Demonstrates a high performance data transfer system using PCI Express® x1
  • Enabling high-performance serial connectivity with GTP ports on FMC, SFP & SMA
  • 128MB DDR3 Component Memory
  • Implement Video display applications with DVI / VGA out
  • Expand I/O with the FPGA Mezzanine Card (FMC) interface

Featured AMD Devices

Featuring the Spartan 6 XC6SLX45T-FGG484-3C FPGA

Logic Cells 43,661
Memory (Kb) 2,088
DSP Slices 58
3.2 Gb/s Transceivers 4
Maximum I/O 296
spartan-6-bk-chip

Product Information

Specifications

Board Features

Featuring the SP605 Evaluation Board

ek-s6-sp605-g
What’s Inside

What's Inside

SP605 Evaluation Board

Featuring the Spartan 6 XC6SLX45T-FGG484-3 FPGA

Power Adapter

Ethernet Cable

Mini USB Cable

ISE™ Design Suite: Logic Edition

Device-locked to the Spartan 6 LX45T FPGA
