All Programmable Cost-Optimized Portfolio

Broadest Cost-Optimized Portfolio

Whether designing an HDMI interface for 4K2K display, an RX beam former for portable ultrasound, or an entire mobile backhaul SoC solution, applications demanding low cost, low density programmable solutions have come to expect a broad feature set for varying levels of integration, performance and power.

The Xilinx All Programmable Cost-Optimized Portfolio comprises four families that are optimized for specific capabilities:

  • Spartan®-6 FPGA for I/O optimization
  • Spartan-7 FPGAs for I/O optimization with the highest performance-per-watt
  • Artix®-7 FPGAs for transceiver optimization and highest DSP bandwidth
  • Zynq®-7000 All Programmable SoCs for system optimization with scalable processor integration



cost-optimized

Key Application Examples

Cost-Optimized Portfolio Maximum Capacity Comparison

  Spartan-6 FPGA
Spartan-7 FPGA Artix-7 FPGA Zynq All Programmable SoCs
Z-7007S, Z-7012S, Z-7014S, Z-7010, Z-7015, Z-7020
Logic Cells 150K 100K 215K 85K
Block RAM 4.8 Mb 4.2 Mb 13 Mb 4.9 Mb
DSP Slices 180 160 740 220
Transceiver Count 8 -- 16 4
Transceiver Speed 3.2 Gb/s -- 6.6 Gb/s 6.6 Gb/s (Z-7012S, Z-7015)
Memory Interface (DDR3)             800 Mb/s
800 Mb/s 1,066 Mb/s 1,066 Mb/s
PCI Express Interface Gen1x1 -- Gen2x4 Gen2x4 (Z-7012S, Z-7015)
Analog Mixed Signal (AMS) / XDAC -- Dual 12-bit 1MSPS ADC with on-chip temp/supply sensors
I/O Pins 576 400 500 328
I/O Standard Support
(40+ protocols supported)
LVDS, Mini-LVDS, Diff HSTL, Diff SSTL, DisplayPort, XAUI, CPRI/OBSAI,
V-by-One, Triple Rate SDI, 6G-SDI (Artix-7 FPGA/Zynq-7000 AP SoCs)

Additional Zynq-7000 All Programmable SoC Specifications

Processor Core

Single- or dual-core ARM® Cortex™-A9 MPCore™ (up to 866MHz)

NEON™ & Single/Double Precision Floating Point for each processor

L1: 32 KB Instruction/32 KB Data per processor
L2: 512 KB, 256 KB OCM

Memory Interfaces DDR3, DDR3L, DDR2, LPDDR2, 2x Quad-SPI, NAND, NOR
Peripherals 2x UART, 2x CAN 2.0B, 2x I2C, 2x SPI, 4x 32b GPIO, 2x USB 2.0 (OTG), 2x Tri-mode Gigabit Ethernet, 2x SD/SDIO

Developer Zone

For FPGA designers looking to shorten design time and ensure scalability and re-use, Xilinx provides a comprehensive suite of solutions ranging from C-based design abstractions to IP plug-and-play to address bottlenecks in hardware development, system-level integration, and implementation.
